MAMBA MICRO X 12.6V ESC, 2A PEAK BEC W / POSTS
Product #: 010-0162-00
Putting the X in Extreme!The Mamba Micro X Crawler edition ESC is our latest offering for the crawling crowd. This ESC is ideal for the weight conscious builder or where space is limited, used in low speed crawling or trail running in vehicles weighing up to 8lbs on 2s or 3s; it can also be used in slightly more aggressive setups like rock racing and extended hill climbing on vehicles up to 4lbs. Recommended motors include Castle's "Slate" crawler motors (combos available) and Holmes Hobbies Puller Pro 540 "Stubby" (≤ 2700kv)
If you're looking for a more aggressive setup in a heavier rig, like rock racing and extended hill climbing, we recommend you run the Mamba X ESC. Your ESC will come with our new V2.02 firmware that has been enhanced for rock crawling and sensored operation.
Note: Use of an external BEC is required if running a high power or digital servo.
This SPECIAL EDITION of the Mamba Micro X includes motor solder posts with 16 AWG wire and 4mm female bullets for the motor connection; 4mm male bullets sold separately.
The Auxiliary Advantage.
Mamba Micro X features the addition of a new, programmable Auxiliary Wire that allows you to make “on-the-go” adjustments to several settings such as torque control, and max throttle, and fine-tune the performance of your ESC right from the transmitter using an auxiliary channel on the receiver. The AUX wire function is disabled by default but is programmable via Castle Link. Once you have programmed the functionality of the AUX wire, that setting can then be adjusted on-the-go from a compatible transmitter. Try out the brand new Crawler Mode for incredible versatility!
The Mamba Micro X is telemetry ready, which means owners of Futaba T4PX or 7PX Transmitters will be able to purchase the Castle Telemetry Link for S.BUS2. Real-time data such as ESC temperature, voltages, and RPM can be monitored to ensure performance advantages and spare you the “unknown” parameters that all R/C enthusiasts experience at some point. Telemetry data provides another level of protection and can increase performance.
Castle Link Compatible
With the optional Castle Link USB Programming Kit you can use your Windows™ PC to easily program your controller. Adjustable settings include:
- Throttle curve
- Braking curve
- Drag brake
- Auto LiPo cutoff
- Punch Control
- Reverse Type
- Motor Type
Additional Castle Link benefits include:
- Access to all firmware updates, including added features sets released from Castle Engineering, at no charge.
- Intuitive Demo Mode capability.
- Ability to save setup profiles for later use.
- Crawler Edition Mamba Micro X w/solder posts
- Castle Sensor Harness adapter
- Coupon for free Castle Link USB adapter
- Driver's Ed and Quick Start Guides
- Castle decal sheet
|Electronic Speed Control (ESC)
|Input Voltage Range:||MIN: 2S LiPo
MAX: 3S LiPo (12.6V)
|BEC Specifications:||Adjustable: 5.5V or 7.5V (2A Peak), default 5.5V. Use of external BEC is recommended if using a high torque/speed digital servo; the CC BEC or CC BEC 2.0 Waterproof are recommended
|Operating Environment:||Waterproof* design allows for use in nearly any environment.|
|Reversible:||Yes, but can be disabled for racing
|On/Off Switch:||Yes, waterproof*|
|Size:||Length: 1.6" (41mm)
Width: 0.75" (19mm)
Height: 1.1" (28mm)
|Weight (without wires):||1.20 oz. (34g)|
|Connectors:||4mm female Castle Bullet Connectors (males sold separately) attached to replaceable 16 gauge wire; includes Castle sensor harness.
|Items Needed for Operation:||Battery Connector required, Castle 4mm polarized Connectors, Deans Ultra Plugs, or Traxxas Power Connect are recommended. 4mm male bullets for motor connection.
|Product Use Statements:||
|Application Guidelines:||Low speed crawling or trail running in vehicles weighing up to 8lbs. If you're looking for a more aggressive setup, like rock racing and extended hill climbing it is recommend to run the Mamba X ESC with the same motor.
|Recommended Motors:||Castle's "Slate" crawler motors (combos available) and Holmes Hobbies Puller Pro 540 "Stubby" (≤ 2700kv)
|Max. Recommended Vehicle Weight:||8lbs when used for low speed/moderate driving style; 4lbs for more aggressive driving styles.
|Programmability:||Fully programmable Castle feature set using Castle Link USB adapter (coupon for free link included in package) and freely downloadable Castle Link Windows software.|
|Telemetry Link Capable:||Yes|
|Tech Notes:||*Not intended for operation while submerged in liquid. If unit is operated in wet conditions, rinse with fresh water to remove dirt or corrosives, then fully dry unit.|
|Mamba Micro X Driver's Guide||Mamba Micro X Quick Start Guide||Sensored Motor Quick Start
- Waterproof : Yes
- Telemetry Capable : Yes
- Data Logging : No
- Auxiliary Wire : Yes
- Minimum Input Voltage : 2S
- Maximum Input Voltage : 3S
- Sensored Capable : Yes
- Recon G6 Certified ESC : No
- ROAR Certified ESC : No
- Availability: Note-This item is out of stock and will be backordered.
This is a high power product with the potential to be very dangerous. Please read the safety information before use. This product may contain chemicals known to the State of California to cause cancer and or birth defects or other reproductive harm.
U.S. Patent # 7400103, 7492122, 7579796, 7740516, 8287328, 8678875, and 8905814 B2 - Other patents pending.
Controller designed, manufactured and supported in Olathe, Kansas USA
